• 1.
  LINUX BOOTING PROCESS Presentedby: Gaurav Sharma 1/13/FET/BCS/2/068 Presentation on:
• 2.
  CONTENTS 1. What isBOOTING? 2. The 6 steps of Linux booting process 3. BIOS 4. MBR 5. GRUB 6. KERNEL 7. Init Process 8. RunLevel Process 9. Thank you!
• 3.
  What is BOOTING? Restartinga computer or its operating system software. It is of two types : (1) Cold booting: when the computer is started after having been switched off. (2) Warm booting: when the operating system alone is restarted (without being switched off) after a system crash or 'freeze.' Both types of booting clear out (for the time being) the bugs, bombs, memory conflicts, and other idiosyncrasies of the operating system.
• 4.
  THE 6 STEPSOF LINUX BOOTING PROCESS
• 5.
  1. BIOS • BIOSstands for Basic Input/Output System • Performs some system integrity checks • Searches, loads, and executes the boot loader program. • It looks for boot loader in floppy, cd-rom, or hard drive. • You can press a key (typically F12 of F2, but it depends on your system) during the BIOS startup to change the boot sequence. • Once the boot loader program is detected and loaded into the memory, BIOS gives the control to it. • So, in simple terms BIOS loads and executes the MBR boot loader.
• 6.
  2. MASTER BOOTRECORD (MBR) • It is located in the 1st sector of the bootable disk. MBR is less than 512 bytes in size. • This has three components 1) primary boot loader info in 1st 446 bytes 2) partition table info in next 64 bytes 3) mbr validation check in last 2 bytes. • It contains information about GRUB . • So, in simple terms MBR loads and executes the GRUB boot loader.
• 7.
  • GRUB standsfor Grand Unified Bootloader. • If you have multiple kernel images installed on your system, you can choose which one to be executed. • GRUB displays a splash screen, waits for few seconds, if you don’t enter anything, it loads the default kernel image as specified in the grub configuration file. • GRUB has the knowledge of the filesystem. • So, in simple terms GRUB just loads and executes Kernel and initrd images. 3. Grand Unified Bootloader (GRUB)
• 8.
  4. KERNEL This canbe considered the heart of operating system responsible for handling all system processes. Kernel is loaded in the following stages: 1. Kernel as soon as it is loaded configures hardware and memory allocated to the system. 2. Next it uncompresses the initrd image (compressed using zlib into zImage or bzImage formats) and mounts it and loads all the necessary drivers. 3. Loading and unloading of kernel modules is done with the help of programs like insmod, and rmmod present in the initrd image. 4. Looks out for hard disk types be it a LVM or RAID. 5. Unmounts initrd image and frees up all the memory occupied by the disk image. 6. Then kernel mounts the root partition as specified in grub.conf as read-only. 7. Next it runs the init process
• 9.
  5. Init Process •Looks at the /etc/inittab file to decide the Linux run level. • Following are the available run levels 0 – halt 1 – Single user mode 2 – Multiuser, without NFS 3 – Full multiuser mode 4 – unused 5 – X11 6 – reboot • Init identifies the default initlevel from /etc/inittab and uses that to load all appropriate program. • If you want to get into trouble, you can set the default run level to 0 or 6. Since you know what 0 and 6 means, probably you might not do that. • Typically you would set the default run level to either 3 or 5.
• 10.
  6. RUNLEVEL PROGRAMS •When the Linux system is booting up, you might see various services getting started. For example, it might say “starting sendmail …. OK”. Those are the runlevel programs, executed from the run level directory as defined by your run level. • Programs starts with S are used during startup. S for startup. • Programs starts with K are used during shutdown. K for kill. • There are numbers right next to S and K in the program names. Those are the sequence number in which the programs should be started or killed.
• 11.
  THANKS! Any questions?
