Outlier Detection Using Unsupervised Learning on High Dimensional Data

Sunil Bhutada Int. Journal of Engineering Research and Application www.ijera.com
ISSN : 2248-9622, Vol. 6, Issue 7, ( Part -3) July 2016, pp.52-56
www.ijera.com 52|P a g e
O
Outlier Detection Using Unsupervised Learning on High
Dimensional Data
Sunil Bhutada1
, Anusha Velicheti2
1
Associate Professor In Sreenidhi Institute Of Science And Technology
2
M.Tech Student In Sreenidhi Institute Of Science And Technology
ABSTRACT
The outliers in data mining can be detected using semi-supervised and unsupervised methods. Outlier
detection in high dimensional data faces various challenges from curse of dimensionality. It means due
to the distance concentration the data becomes unobvious in high dimensional data. Using outlier
detection techniques, the distance base methods are used to detect outliers and label all the points as
good outliers. In high dimensional data to detect outliers effectively, we use unsupervised learning
methods like IQR, KNN with Anti hub.
Index Terms: Outlier detection, unsupervised and semi-supervised learning, high dimensional data.
I. INTRODUCTION
UTLIERS is the data objects that
do not comply with the general
behavior or model of the data, such
data objects which are grossly different from
or inconsistent with the remaining set of data
are called outliers[1][3].
Outliers are of three types: supervised, semi-
supervised and unsupervised.
1. Supervised learning is a task of
machine learning which infer a utility from
labeled training data. The data consist of a set
of training examples. It consists a pair of an
input object (vector) and a desired output
value (supervisory signal). 2. Unsupervised
learning is a type of machine learning
algorithm used to draw inferences from
datasets consisting of input data without
labeled responses .The most common
unsupervised learning method is cluster
analysis, which is used for exploratory data
analysis to find hidden patterns or grouping
in data[6]. 3. Semi-supervised learning is a
class of supervised learning tasks and
techniques that also make use of unlabeled
data for training small amount of labeled data
with a large amount of unlabeled data. Semi-
supervised learning falls between
unsupervised learning (without any labeled
training data) and supervised learning (with
completely labeled training data
Supervised/unsupervised is the best way for
basic data mining. There are 4 main tasks
prediction, modeling, similarity and
association. Prediction: If you are predicting a
real number, it is called a regression. If you are
predicting a whole number or a class, it is
called a classification. Modeling: modeling is
the same as prediction, but the model is
comprehensible by humans, neural networks,
and support vector machines work great, but
do not produce comprehensible models,
decision trees and classic linear regression are
examples of easy to understand models.
Similarity: If you are trying to find natural
groups of attributes, it is called factor
analysis. If you are trying to find natural
groups of observation , it is called clustering.
Association: It is much like correlation, but for
enormous binary datasets.
1.1 Problem Statement
An outlier is an observation that
appears to deviate markedly from other
observations in the sample. Outlier may
origin anomalous causes (the inconsistent data
or any missing values). In some cases, it is
not always possible to determine if an
outlying point as bad data. Outliers may be
due to random variation or may indicate
something scientifically interesting. The
following three issues regards to outliers:
RESEARCH ARTICLE OPEN ACCESS

Outlier labeling is a flag potential outlier
for further investigation.
Outlier accommodation is used for
robust statistical techniques that will not be
unduly affected by outliers.
Outlier identification formally test
whether observations are outliers. The outlier
mining problem can be viewed as sub
problems a. Define what data can be
considered as inconsistent in a given data
set. b. Find an efficient method to mine
outliers so defined.
These problems can be solved by
using following methods for outlier detection
1. The statistical approach
2. The distance based approach
3. The density based local outlier approach
4. The deviation based approach.
When the outlier detection is risky
that can be solved by distance based
approach.
1.2 Theory
Outlier detection in high-
dimensional data presents various
challenges resulting from the curse of
dimensionality. High dimensional data is the
cluster analysis of data with anywhere
from many dimensions. Curse of
dimensionality arise when analyzing and
organizing data in high dimensional spaces
that do not occur in low dimensional
settings. Some outliers can be designed
to detect the presence of a single outlier
while other tests are designed to detect the
presence of multiple outliers. These can be
grouped by the following characteristics:
a) What is the distributional model
for the data? We restrict our discussion to
tests that assume the data follow an
approximately normal distribution. Is the
test designed for a single outlier or is it
designed for multiple outliers? If the test is
designed for multiple outliers, does the
number of outliers need to be specified
exactly or can we specify an upper bound
for the number of outliers? The following
are a few of the more commonly used
outlier tests for normally distributed data. This
list is not exhaustive. The tests given here
are essentially based on the criterion of
distance based method. The distance based
method is one of the methods in anomaly
detection. Anomalies: the set of objects are
considerably dissimilar from the remainder
of the data. They occur relatively
infrequently. When they do occur, their
consequences can be quite dramatic and quite
often in a negative sense. Anomaly is a
pattern in the data that does not conform
to the expected behavior. It is also referred as
outliers, exceptions, peculiarities, surprise, etc.
Anomalies translate to significant (often
critical) real life entities like Cyber
intrusions, Credit card fraud[2].
Type of Anomalies: Point Anomalies,
Contextual Anomalies, Collective Anomalies.
Point Anomalies: An individual data
instance is anomalous with respect to the data.
Output of Anomaly Detection:
Label: Each test instance is given
a normal or anomaly label. This is
especially true of classification-based
approaches. Score: Each test instance is
assigned an anomaly score. It allows the
output to be ranked and also it requires an
additional threshold parameter.
II. OUTLIER DETECTION SCHEMES
Anomaly Detection Schemes:
General Steps for anomaly detection is to
build a profile of the normal behavior.
Profile can be in patterns or summary
statistics for the overall population. Use the
normal profile to detect anomalies.
Anomalies are observations whose
characteristics differ significantly from the
normal profile.

Anomaly detection methods: 1.
Statistical- based 2. Model-based 3.
Distance-based Outlier Detection
Distance based methods define outlier
as an observation that is D min distance
away from p percentage of observations in
the dataset. The problem is then finding
appropriate D min and p such that outliers
would be correctly detected with a small
number of false detections. This process
usually needs domain knowledge. For
measuring distance based outliers, we use
KNN(K-Nearest neighbor). From different
datasets, we identify outliers by forming
clusters. The data which is outside the clusters
are identified as outliers. Distance- based
Approaches : Data is represented as a vector
of features. Three major approaches
a. Nearest-neighbor based b. Density based
c. Clustering based.
Nearest-Neighbor Based Approach:
Compute the distance between every
pair of data points. Nearest neighbor based
outlier detection techniques can be broadly
grouped into two categories based on how
they compute the outlier score 1) Distance to
Kth Nearest Neighbor Based[5] These
techniques use the distance of a data instance
to its kth nearest neighbor as the outlier
score. 2) Relative Density Based These
techniques compute the relative density of
each data instance to compute its outlier
score. 3) Using Other Manners - Additionally
there are some techniques that use the
distance between data instances in a different
manner to detect outliers.
2.1 Nearest Neighbor Based Outlier
Detection
Given two points p and q, we use dist
(p,q) to denote the Euclidean distance
between p and q. A k-Nearest- Neighbors
query kNN(q,k,P) on a dataset P finds the set
of k objects that are nearest to the query
location q. Formally, an object p 2 P is in
the result of kNN(q; k; P) if and only if it
satisfies the following condition:
— o ∈ P |dist(o, q) < dist(p, q)| < k. The
idea of distance based outliers is extended by
using the distance to the k-nearest neighbor
to rank the outliers. Nearest Neighbor (NN)
is finding the point closer to the query point
in a given data set and a query point in k
dimensional space. As dimensionality
increases, the distance to the nearest data point
approaches the distance to the farthest data
point[3].
Definition Of Hubs And Antihubs
Definition 1: For q ∈ (0, 1), hubs are the
nq
points x ∈ D with the highest values of
Nk(x).
Definition 2: For p ∈ (0, 1), p <1-q, antihubs
are the np points x ∈ D with the lowest
values of Nk(x).
The anti hub method is unsupervised
outlier detection method used for anomaly
detection in high dimensional dataset. The
data set exhibits that as dimensionality
increases there exists hubs and anti hubs .
Hubs are the point that frequently occurs in
k-nearest neighbors. Anti hubs are the point
that occurs infrequently in nearest neighbors
list. Discrimination of outlier scores
produced by Anti hub acquires longer period
of time with larger number of iterations.
The advantage of this method is, it gives
more accurate result as compared to the
unsupervised distance based method[7][8].
The method is implemented with
four phases.
1) Import the data set.
2) Preprocess the data set. Here
unsupervised learning approach is used.
3) Calculation of anti hub using the entropy
of objects.
4) Outlier detection results.
Architecture:
2.1.1 Algorithm
Input:
1. Training data set and objects
2. Test data set.
Output: H(X) Entropy of objects.
1. Outlier Set. 1. Initialize Objects in the data
set.
2. Do. For each example data in the
training set
a. T-Training data set b. Outlier set
b. X is object

c. Calculate E threshold value e. Obtain
Entropy
d. f. Detection of outlier set
3. Return the data set.
IQR [Inter Quartile Range] is another method
to detect outliers.
2.2 IQR
The inter quartile range(IQR) is a
measure of variability, based on dividing a
data set into quartiles. Quartiles divide a
rank-ordered data set into four equal parts.
The values that divide each part are called the
first, second, and third quartiles; and they
are denoted by Q1, Q2, and Q3,
respectively.IQR is used in statistical analysis
to help draw conclusions about a set of
numbers. The IQR is often preferred over
the range because it excludes most outliers.
2.2.1 Algorithm
1. Data arranged in order.
2. Calculate first quartile data (Q1)
3. Calculate third quartile data (Q3)
4. Calculate inter quartile data range
(IQR)=Q3- Q1
5. Calculate lower boundary values = Q1-
(1.5*IQR)
6. Calculate upper boundary values =
Q3+(1.5*IQR)
7. Anything outside the lower and upper
boundary value is an outlier.
III. CONCLUSION
The distance based outlier detection is
per- formed on high dimensional datasets. The
existence of hubs and anti hubs in high
dimensional data is relevant to machine-
learning techniques from various families:
supervised, semi supervised, as well as
unsupervised. Outlier scores also play an
important role in outlier detection. This
Paper provides a detailed survey of literature
on distance based outlier detection. Based on
the analysis, we illustrate the IQR and KNN
with Anti Hub method for semi- supervised
and unsupervised outlier detection. It
improves accuracy and efficiency of distance
based outlier detection.
REFERENCES
[1]. Jayshree S.Gosavi and Vinod.S.
Wadne, Outlier Detection using
Semi-supervised and Unsupervised
Learning on High Dimensional Data,
International Journal of Computer
Application (2250-1797)Volume 5 No.
5, August 2015
[2]. V. Chandola, A. Banerjee, and V.
Kumar, Anomaly detection: A
survey,60 ACM Comput Surv, vol. 41,
no. 3, p. 15, 2009.
[3]. Ville Hautamaki, Ismo Karkk ainen and
Pasi Franti, Outlier Detection Using k-
Nearest Neighbour Graph,
Proceedings of the 17th International
Conference on Pattern Recognition
(ICPR04) 1051-4651/04 IEEE
[4]. Hans-Peter Kriegel, Peer Krger,
Arthur Zimek, Outlier Detection
Techniques, The 2010 SIAM
International Conference on Data
Mining
[5]. Smita Patil , P. D.Chouksey, ”A Survey
On: Distance Based Outlier
Detection”, international Journal of
Science and Re- search (IJSR)
[6]. Jayshree S.Gosavi ,
Vinod S.Wadne, ”Unsupervised
Distance-Based Outlier Detection
Using Nearest Neighbours
Algorithm on
Distributed Approach: Survey”,
International Journal of
Innovative Research in Computer
and Communication Engineering
[7]. Mrs. R. Lakshmi Devi, Dr. R. Amalraj,
”An Efficient Unsupervised Adaptive
Anti hub Technique for Outlier
Detection in High Dimensional
Data”, The International Journal Of
Engineering And Science
(IJES)Volume 4 Issue 11 Pages PP -
70-77 2015
[8]. J. Michael Antony Sylvia, Dr. T. C.
Rajakumar, ”RECURSIVE ANTIHUB 2
OUTLIER DETECTION IN HIGH
DIMEN- SIONAL DATA”.
Sunil Bhutada Graduated
in B.E.(CSE) from
Amravathi University in
1993. He received Masters
Degree in M.Tech.(Software
Engineering), from JNT
University, Hyderabad, in 2006. He worked as
Software Engineer thereafter and later
shifted to academics in 1998. He is currently
attached with Sreenidhi Institute of Science
Technology in Hyderabad as Associate
Professor in IT department. His areas of
interest include Data Mining, Information
Security, Information Retrieval System
Presently he is pursuing Ph.D from

Jawaharlal Nehru Technological University,
Hyderabad, India, in the field of Data Mining.
Anusha Velicheti is studying
M.Tech (CNIS) in Sreenidhi
Institute of Science
Technology, Yamnampet,
Gatkesar, Hyderabad. She
completed B.Tech in CSE
in the year 2012 from JNT
University, Hyderabad. Her research interest
include Data Mining.

Outlier Detection Using Unsupervised Learning on High Dimensional Data

More Related Content

What's hot

Similar to Outlier Detection Using Unsupervised Learning on High Dimensional Data

Recently uploaded

Outlier Detection Using Unsupervised Learning on High Dimensional Data
